This series of reduction gearbox is used as a gearbox equipment for the submersible pump on the bridge frame of the dredger. The gearbox has a horizontal eccentric structure and does not come with a clutch.
Model | JH1900 |
Input speed (rpm) | 993 |
Reduction ratio | 3.762:1 |
Transmission capacity (Kw/rpm) | 1.9134 |
Length x width x height | 1445*948*150 |
Weight kg | 1340 |
Structure | Horizontal out of the center, input-output opposite direction |
